Features Power factor: 0.9 Output power capacity: 3 kVA Efficiency: 90% UPS topology: Double-conversion (Online) Output power: 2700 W Emergency Power Off (EPO): Yes Input current Total Harmonic Distortion (THD): 5% Output operation voltage (min): 220 V Waveform: Sine Input frequency: 40 - 70 Hz Crest factor: 3:1 Input operation voltage (max): 300 V Output voltage Total Harmonic Distortion (THD): 5% Noise level: 50 dB Output operation voltage (max): 240 V Input operation voltage (min): 176 V
Design Product colour: Black Display type: LCD
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 95%
Weight & dimensions Depth: 399 mm Height: 328 mm Width: 190 mm Weight: 22.2 kg
Packaging data Package height: 464 mm Package width: 324 mm
Packaging content Cables included: Input power cable, USB cable Manual: Yes
Ports & interfaces Emergency Power Off (EPO) connector: Yes AC outlet types: C13 coupler, C19 coupler RS-232 ports: 1 AC outlets quantity: 5 AC outlet(s) USB port: Yes Power plug: C20 coupler
Battery Typical backup time at full load: 3.9 min Battery capacity: 9 Ah Battery recharge time: 4 h Typical backup time at half load: 11.7 min Number of batteries supported: 6 Battery voltage: 12 V
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock.
