Features Output power: 6000 W UPS topology: Double-conversion (Online) Efficiency: 94% Input frequency: 46/64 Hz Output operation voltage (min): 208 V Output power capacity: 6 kVA Hold time (max): 0 ms Output voltage regulation: -1 - 1% Output frequency regulation: -0.1 - 0.1 Hz Noise level: 55 dB Crest factor: 3:1 Input power factor: 0.99 Output power factor: 1 Input operation voltage (max): 300 V Emergency Power Off (EPO): Yes Input operation voltage (min): 110 V Output operation voltage (max): 240 V Response time: 0 ms
Design Display type: LCD Form factor: Tower LED indicators: Yes Product colour: Black Cooling type: Active
Operational conditions Operating relative humidity (H-H): 20 - 95% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Width: 190 mm Height: 688 mm Depth: 369 mm Weight: 59 kg Bundled software: ViewPower
Packaging data Package depth: 485 mm Package width: 280 mm Resource CD: Yes Package height: 785 mm Package weight: 63 kg
Packaging content Manual: Yes Cables included: USB cable
Ports & interfaces Emergency Power Off (EPO) connector: Yes Power plug: Terminal AC outlet types: Terminal RS-232 ports: 1 USB 2.0 ports quantity: 1 AC outlets quantity: 1 AC outlet(s)
Battery Typical backup time at full load: 3.7 min Charging current: 1 A Typical backup time at half load: 11.2 min Number of batteries supported: 16 Battery voltage: 12 V Battery capacity: 9 Ah
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Use the appliance in well-ventilated areas to avoid overheating., Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water.
