Features Number of output phases: 1 Output voltage Total Harmonic Distortion (THD): 3% Emergency Power Off (EPO): Yes Waveform: Pure sine Output power factor: 0.9 UPS topology: Line-Interactive Number of input phases: 1 Efficiency (On-line mode): 98.8% Efficiency (ECO mode): 82.3% Output voltage regulation: 10% Input operation voltage (max): 290 V Automatic Voltage Regulation (AVR): Yes Input operation voltage (min): 165 V Power protection features: Overload Output power: 900 W Input frequency: 45/65 Hz Noise level: 40 dB Output power capacity: 1 kVA Response time: 6 ms Power source type: AC
Design Built-in fan: Yes Form factor: Rackmount/Tower Display type: LCD International Protection (IP) code: IP20 Rack capacity: 2U Product colour: Black LED indicators: Yes
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 5 - 90%
Weight & dimensions Width: 438 mm Height: 88 mm Depth: 430 mm Weight: 16 kg
Packaging data Package weight: 18 kg Package height: 231 mm Package depth: 550 mm Package width: 556 mm
Ports & interfaces SmartSlot: Yes USB port type: USB Type-B AC outlet types: C13 coupler RS-232 ports: 1 USB port: Yes Power plug: C14 coupler AC outlets quantity: 8 AC outlet(s)
Battery Battery voltage: 12 V Battery capacity: 9 Ah Charging current: 6 A Off-mode charging: Yes Typical backup time at full load: 2 min Number of batteries supported: 2 Typical backup time at half load: 8 min Cold start: Yes Battery recharge time: 4 h
Other features Nominal output voltage: 230 V
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water., Use the appliance in well-ventilated areas to avoid overheating.
