Features Response time: 10 ms Power factor: 0.7 Efficiency (On-line mode): 88% Output frequency regulation: ±1 Hz Input operation voltage (min): 162 V Noise level: 45 dB Output power: 1050 W Audible alarm(s): Yes Crest factor: 3:1 Input frequency: 50/60 Hz Input operation voltage (max): 290 V UPS topology: Line-Interactive Maximum current: 1.4 A Waveform: Sine Output operation voltage (max): 240 V Output operation voltage (min): 208 V Output power capacity: 1.5 kVA Efficiency: 96%
Design LED indicators: Battery replacement, Fault Product colour: Black Display type: LCD Form factor: Tower
Operational conditions Operating relative humidity (H-H): 20 - 95% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Weight: 13.8 kg Width: 145 mm Depth: 397 mm Height: 220 mm
Packaging data Package height: 325 mm Package width: 230 mm
Packaging content Manual: Yes
Ports & interfaces AC outlets quantity: 6 AC outlet(s) USB port: Yes RS-232 ports: 1 Emergency Power Off (EPO) connector: Yes AC outlet types: C13 coupler Power plug: C14 coupler
Battery Battery voltage: 12 V Battery capacity: 9 Ah Number of battery cells: 2 Battery recharge time: 4 h Typical backup time at half load: 8.9 min Charging current: 1.4 A Typical backup time at full load: 2.2 min
Logistics data Harmonized System (HS) code: 85078000
Safety warning Warnings: Use the appliance in well-ventilated areas to avoid overheating., Do not disassemble the unit housing, there may be a risk of electric shock., Keep away from sources of fire and water.
