Features Output operation voltage (min): 230 V Output voltage regulation: 10% Output power capacity: 2.2 kVA UPS topology: Line-Interactive Efficiency: 95% Output operation voltage (max): 230 V Output frequency regulation: 1 Hz Output power: 1200 W Output power factor: 0.55 Input frequency: 50/60 Hz Input operation voltage (min): 170 V Input operation voltage (max): 280 V
Design Form factor: Mini Tower Product colour: Black Display type: LCD
Operational conditions Operating relative humidity (H-H): 0 - 90% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Package width: 230 mm Height: 195 mm Package height: 292 mm Weight: 10.2 kg Depth: 364 mm Width: 139 mm Bundled software: WinPower
Packaging data Cables included: Input power cable, USB cable Manual: Yes Quick installation guide: Yes
Ports & interfaces Ethernet LAN (RJ-45) ports: 1 USB port: Yes AC outlet types: C13 coupler Modem (RJ-11) ports: 1 AC outlets quantity: 4 AC outlet(s) USB 2.0 ports quantity: 1 Power plug: C14 coupler
Battery Battery capacity: 9 Ah Typical backup time at full load: 0.5 min Battery recharge time: 4 h Typical backup time at half load: 5 min Battery voltage: 12 V
Logistics data Harmonized System (HS) code: 85078000
