Features ECO mode: Yes Number of input phases: 1 Waveform: Pure sine Automatic Voltage Regulation (AVR): Yes Input operation voltage (min): 165 V Input frequency: 45/65 Hz Input operation voltage (max): 290 V UPS topology: Line-Interactive Output power capacity: 3 kVA Power protection features: Overload Output power factor: 0.9 Output voltage regulation: 10% Efficiency (On-line mode): 98.8% Number of output phases: 1 Emergency Power Off (EPO): Yes Power source type: AC Response time: 6 ms Output power: 2700 W Noise level: 45 dB
Design Display type: LCD International Protection (IP) code: IP20 Product colour: Black Rack capacity: 2U Form factor: Rackmount/Tower LED indicators: Yes
Operational conditions Operating relative humidity (H-H): 5 - 90% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 610 mm Weight: 18 kg Height: 88 mm Width: 438 mm
Packaging data Package width: 556 mm Package height: 550 mm Package weight: 20 kg Package depth: 231 mm
Ports & interfaces USB port: Yes Power plug: C14 coupler AC outlet types: C13 coupler USB port type: USB Type-B SmartSlot: Yes RS-232 ports: 1 AC outlets quantity: 8 AC outlet(s)
Battery Battery recharge time: 4 h Cold start: Yes Charging current: 6 A Typical backup time at full load: 2.5 min Typical backup time at half load: 9 min Battery capacity: 9 Ah Number of batteries supported: 6 Battery voltage: 12 V
Safety warning Warnings: Do not disassemble the unit housing, there may be a risk of electric shock., Use the appliance in well-ventilated areas to avoid overheating., Keep away from sources of fire and water.
