Features Output frequency regulation: 0.5 Hz Input frequency: 45/55 Hz Output power factor: 0.6 Waveform: Sine Power protection features: Overload Output power capacity: 0.5 kVA UPS topology: Line-Interactive Output operation voltage (max): 230 V Output operation voltage (min): 230 V Output voltage regulation: 10% Input operation voltage (max): 290 V Input operation voltage (min): 165 V Output power: 300 W
Design Display type: LCD Form factor: Rackmount Product colour: Black Rack capacity: 1U
Operational conditions Operating relative humidity (H-H): 0 - 95% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Width: 433 mm Weight: 7.6 kg Depth: 216 mm Height: 44 mm
Packaging data Package height: 150 mm Package width: 537 mm Package depth: 317 mm
Packaging content Manual: Yes Cables included: USB cable
Ports & interfaces RS-232 ports: 1 Emergency Power Off (EPO) connector: Yes AC outlet types: C13 coupler USB port: Yes AC outlets quantity: 4 AC outlet(s)
Battery Battery voltage: 6 V Typical backup time at full load: 0.8 min Number of batteries supported: 2 Typical backup time at half load: 10.3 min Battery recharge time: 8 h Battery capacity: 7 Ah
Logistics data Harmonized System (HS) code: 85078000
