Features Output power capacity: 0.8 kVA UPS topology: Line-Interactive Output power factor: 0.6 Noise level: 40 dB Input frequency: 50/60 Hz Surge energy rating: 156 J Power protection features: Overload, Overdischarge, Overcharge Waveform: Sine Response time: 6 ms Output operation voltage (max): 230 V Output power: 480 W Input operation voltage (max): 280 V Input operation voltage (min): 170 V
Design Form factor: Compact Product colour: Black LED indicators: Yes
Weight & dimensions Depth: 345 mm Weight: 5.5 kg Width: 200 mm Height: 100 mm
Packaging data Package height: 269 mm Package depth: 425 mm Package width: 146 mm Package weight: 5.8 kg
Ports & interfaces USB port type: USB Type-B AC outlet types: Type E USB port: Yes AC outlets quantity: 8 AC outlet(s) Ethernet LAN (RJ-45) ports: 1 Serial interface: Yes RS-232 ports: 1
Battery Number of batteries supported: 1 Battery capacity: 9 Ah Typical backup time at full load: 0.1 min Typical backup time at half load: 1.2 min Battery recharge time: 8 h Battery voltage: 12 V Charging current: 1 A
Logistics data Harmonized System (HS) code: 85078000
