Features Output operation voltage (max): 240 V Power protection features: Overload, Short circuit, Overcharge, Battery discharge Automatic Voltage Regulation (AVR): Yes Output power capacity: 0.8 kVA Efficiency: 96.2% Waveform: Pure sine Output voltage regulation: 10% Output frequency: 50/60 Hz Audible alarm(s): Yes Output power factor: 0.6 UPS topology: Line-Interactive Surge protection: Yes Output frequency regulation: 1 Hz Input operation voltage (min): 162 V Audible alarm modes: Alarm when on battery, Fault, Low battery alarm Input operation voltage (max): 290 V Output operation voltage (min): 220 V Input frequency: 50/60 Hz Output power: 480 W
Design Display type: LCD Product colour: Black Form factor: Compact
Operational conditions Operating temperature (T-T): 0 - 40 °C Operating relative humidity (H-H): 0 - 90%
Weight & dimensions Weight: 6 kg Depth: 328 mm Height: 145 mm Width: 100 mm
Packaging data Software CD: Yes Package width: 140 mm Package depth: 385 mm Package height: 228 mm
Packaging content Cables included: Input power cable, USB cable Manual: Yes
Ports & interfaces AC outlet types: Type E USB port: Yes Ethernet LAN (RJ-45) ports: 2 USB 2.0 ports quantity: 1 AC outlets quantity: 2 AC outlet(s)
Battery Battery recharge time (90%): 7 h Typical backup time at half load: 5 min Battery capacity: 9 Ah Battery voltage: 12 V Number of batteries supported: 1
Logistics data Master (outer) case gross weight: 27.5 kg Master (outer) case height: 250 mm Master (outer) case width: 580 mm Products per pallet: 128 pc(s) Master (outer) case length: 390 mm Products per master (outer) case: 4 pc(s) Harmonized System (HS) code: 85078000
