Features Surge protection: Yes Automatic Voltage Regulation (AVR): Yes Input operation voltage (min): 162 V Input frequency: 50/60 Hz Efficiency: 95% Output power: 480 W UPS topology: Line-Interactive Output power factor: 0.56 Output power capacity: 0.85 kVA Output voltage regulation: 10% Input operation voltage (max): 290 V Output operation voltage (max): 230 V
Design Display type: LCD Product colour: Black Form factor: Compact
Operational conditions Operating relative humidity (H-H): 0 - 90% Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Width: 100 mm Depth: 290 mm Height: 143 mm Package height: 226 mm Weight: 5.2 kg Package width: 139 mm
Packaging data Cables included: USB cable Resource CD: Yes Manual: Yes
Ports & interfaces USB port: Yes Modem (RJ-11) ports: 2 AC outlets quantity: 2 AC outlet(s)
Battery Battery recharge time (90%): 4 h Typical backup time at half load: 6 min Battery capacity: 9 Ah Typical backup time at full load: 0.6 min Battery voltage: 12 V Number of batteries supported: 1
Logistics data Harmonized System (HS) code: 85078000 Master (outer) case width: 380 mm Products per master (outer) case: 4 pc(s) Master (outer) case gross weight: 23.1 kg Master (outer) case height: 250 mm Master (outer) case length: 598 mm
