Processor
Processor manufacturer: Intel
Processor threads: 4
Processor cores: 4
Processor model: J6412
Processor cache: 1.5 MB
Processor frequency: 2 GHz
Processor family: Intel® Celeron®
On-board graphics card model: Intel® UHD Graphics
Processor boost frequency: 2.6 GHz
Memory
Flash memory: 4000 MB
Internal memory: 8 GB
Maximum RAM supported: 8 GB
Design
Cooling type: Active
Chassis type: Tower
Drive bay locking: Yes
Cable lock slot type: Kensington
Number of fans: 1 fan(s)
Fan diameter: 7 cm
Product colour: Black
LED indicators: LAN, Status, USB, Power, HDD
Cable lock slot: Yes
Power
Power consumption (typical): 24.238 W
Fan voltage: 12 V
Number of power supply units: 1
Power consumption (sleep): 20.943 W
Power supply location: External
AC input voltage: 100 - 240 V
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 70 °C
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 169.2 mm
Package depth: 205 mm
Package height: 240 mm
Depth: 220.5 mm
Width: 102 mm
Package width: 275 mm
Package weight: 2.57 kg
Weight: 1.28 kg
Network
Wake-on-LAN ready: Yes
Ethernet LAN: Yes
Dynamic DNS (DDNS): Yes
iSCSI support: Yes
DHCP server: Yes
Jumbo frames support: Yes
Ethernet LAN data rates: 2500 Mbit/s, 10, 100, 1000 Mbit/s
Performance
USB copy function: Yes
On/off switch: Yes
Management protocols: SNMP V2/V3
Share folder: 512
Access Control List (ACL): Yes
Share folder access right management: Yes
Hot spare: Yes
Password authentication: Yes
Built-in FTP server: Yes
System log: Yes
Disk scan: Yes
Snapshot: Yes
Buzzer: Yes
Backup features: Cloud, iSCSI LUN, USB drive
S.M.A.R.T. support: Yes
Browser supported: Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
Backup button: Yes
Multilingual support: Yes
Backup function: Yes
Device class: Small & Medium Business
Security algorithms: SNMPv3, SNMPv2, HTTPS, FIPS 140-2, SSH
Reset button: Yes
Type: NAS
Packaging content
Cables included: LAN (RJ-45), AC
Drive tray key included: Yes
Number of screws: 16
Power cables quantity: 1
External power adapter: Yes
Package type: Box
Software
Linux operating systems supported: Ubuntu 14.04
Windows operating systems supported: Windows 7, Windows 8, Windows 11, Windows 10
Mac operating systems supported: Yes
Server operating systems supported: Windows Server 2008 R2, Windows Server 2012, Windows Server 2019, Windows Server 2012 R2, Windows Server 2016
Operating system installed: QNAP QTS
Operating system version: 5.0.1
Storage
Storage drive sizes supported: 2.5, 3.5", M.2
Online RAID migration: Yes
RAID levels: JBOD, 1, 0
Number of storage drives supported: 2
Online RAID expansion: Yes
Disk roaming: Yes
RAID rebuild: Yes
Number of M.2 (M & B) slots: 2
Supported file systems: FAT32, ext4, exFAT, HFS+, ext3, NTFS
Installed storage drive type: No
Hot-swap drive bays: Yes
Storage drives installed: No
Total installed storage capacity: 0 TB
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, Serial ATA III
Ports & interfaces
Concurrent connections: 1500
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI ports quantity: 2
HDMI version: 1.4b
USB port: Yes
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 2
Other features
Warranty period: 3 year(s)
Safety warning
Warnings: Do not dispose of the device in the regular rubbish bin. The product requires special disposal., Avoid contact with liquids., Do not dismantle the appliance yourself.
