Processor
Processor frequency: 2.2 GHz
Processor cores: 4
Processor manufacturer: Marvell
Processor model: CN9131
Processor family: Marvell
Memory
Internal memory: 4 GB
Flash memory: 4000 MB
Memory form factor: SO-DIMM
Maximum RAM supported: 32 GB
Internal memory type: DDR4
Memory slots: 1
Design
LED indicators: Yes
Cable lock slot: Yes
Chassis type: Rack (1U)
Cooling type: Active
Product colour: Grey, Black
Fan diameter: 4 cm
Cable lock slot type: Kensington
Number of fans: 3 fan(s)
Power
Fan voltage: 12 V
AC input voltage: 100 - 240 V
Power consumption (typical): 30.878 W
Power consumption (HDD standby): 17.367 W
Number of power supply units: 1
Power supply unit (PSU) capacity: 100 W
AC input frequency: 50 - 60 Hz
Power supply location: Built-in
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -20 - 70 °C
Weight & dimensions
Width: 439 mm
Weight: 4.17 kg
Height: 44 mm
Package weight: 5.86 kg
Depth: 291 mm
Package depth: 179 mm
Package width: 415 mm
Package height: 542 mm
Network
Wake-on-LAN ready: Yes
DHCP client: Yes
Load balancing system: Yes
Ethernet LAN data rates: 2500 Mbit/s, 100, 10000 Mbit/s, 1000 Mbit/s
iSCSI support: Yes
Dynamic DNS (DDNS): Yes
Ethernet LAN: Yes
DHCP server: Yes
Link aggregation: Yes
Jumbo frames support: Yes
Performance
Backup function: Yes
Buzzer: Yes
Share folder: Y
Device class: Small & Medium Business
Access Control List (ACL): Yes
Backup features: iSCSI LUN, Cloud
Browser supported: Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox, Microsoft Edge
Multilingual support: Yes
Universal Plug and Play (UPnP): Yes
Built-in FTP server: Yes
Reset button: Yes
Type: NAS
Snapshot: Yes
Remotely operated: Yes
Disk scan: Yes
On/off switch: Yes
System log: Yes
S.M.A.R.T. support: Yes
Hot spare: Yes
Packaging content
Package type: Box
Power cables quantity: 1
Number of screws: 28
Cables included: LAN (RJ-45), AC
Rack mount kit: Yes
Software
Server operating systems supported: Windows Server 2012 R2, Windows Server 2016, Windows Server 2008 R2, Windows Server 2019, Windows Server 2012
Linux operating systems supported: Yes
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Operating system installed: QNAP QTS
Operating system version: 5.0.0
Storage
Supported storage drive types: HDD & SSD
Bad block scan: Yes
RAID rebuild: Yes
Auto-rebuild: Yes
Online RAID migration: Yes
Disk roaming: Yes
Storage drive sizes supported: 2.5, 3.5", M.2
Supported storage drive interfaces: M.2, Serial ATA II, Serial ATA III
RAID support: Yes
Storage drives installed: No
Online RAID expansion: Yes
RAID levels: 1, 6, JBOD, 5, 10, 0
Number of storage drives supported: 4
Supported file systems: FAT32, exFAT, ext4, HFS+, ext3, NTFS
Hot-swap drive bays: Yes
Installed storage drive type: No
Total installed storage capacity: 0 TB
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Fiber ports quantity: 2
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 2
Fiber optic connector: SFP+
Concurrent connections: 1500
USB port: Yes
Other features
Warranty period: 3 year(s)
Logistics data
Harmonized System (HS) code: 84714100
Safety warning
Warnings: Do not dispose of the device in the regular rubbish bin. The product requires special disposal., Avoid contact with liquids., Do not dismantle the appliance yourself.
