Features Input operation voltage (max): 300 V Input operation voltage (min): 115 V Output operation voltage (max): 240 V Power protection features: Short circuit, Over voltage, Overload Output frequency regulation: 0.05 Hz Output operation voltage (min): 220 V Noise level: 50 dB Output power: 800 W UPS topology: Double-conversion (Online) Output voltage regulation: 5% Waveform: Pure sine Output power capacity: 1 kVA Maximum current: 3.6 A Output frequency: 50/60 Hz
Design Control type: Buttons LED indicators: Yes Cooling type: Passive Form factor: Compact Product colour: Black Display type: LCD Built-in fan: Yes
Operational conditions Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): -30 - 45 °C
Weight & dimensions Height: 220 mm Width: 145 mm Depth: 270 mm Weight: 9.4 kg
Packaging data Package type: Box Package weight: 10.3 kg
Ports & interfaces USB port type: USB Type-B Serial interface: Yes RS-232 ports: 1 Ethernet LAN (RJ-45) ports: 2 USB 2.0 ports quantity: 1 AC outlet types: Type F Serial interface type: RJ-45, RS-232 AC outlets quantity: 2 AC outlet(s) USB port: Yes
Battery Battery capacity: 9 Ah Number of batteries supported: 2 Battery voltage: 24 V Charging current: 5 A
