Features Output frequency regulation: 0.05 Hz UPS topology: Double-conversion (Online) Output voltage regulation: 5% Output power capacity: 3 kVA Noise level: 50 dB Power protection features: Short circuit, Over voltage, Overload Input operation voltage (max): 300 V Input operation voltage (min): 115 V Waveform: Pure sine Output operation voltage (min): 220 V Output power: 2400 W Maximum current: 16 A Output frequency: 50/60 Hz Output operation voltage (max): 240 V
Design Control type: Buttons LED indicators: Yes Form factor: Compact Display type: LCD Built-in fan: Yes Product colour: Black Cooling type: Passive
Operational conditions Operating temperature (T-T): 0 - 40 °C Storage temperature (T-T): -30 - 45 °C
Weight & dimensions Height: 220 mm Width: 145 mm Package type: Box Depth: 270 mm Weight: 9.4 kg
Ports & interfaces USB port type: USB Type-B RS-232 ports: 1 Ethernet LAN (RJ-45) ports: 2 AC outlet types: Type F Serial interface type: RJ-45, RS-232 Serial interface: Yes AC outlets quantity: 2 AC outlet(s) USB 2.0 ports quantity: 1 USB port: Yes
Battery Number of batteries supported: 8 Battery capacity: 7 Ah Charging current: 5 A Battery voltage: 96 V
