Processor
Motherboard chipset: AMD B650E
Processor family: AMD
Number of processors supported: 1
Built-in processor: No
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD EPYC 4004 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
On-board graphics card model: Aspeed AST2600
On-board graphics card: Yes
Features
Trusted Platform Module (TPM) version: 2.0
Trusted Platform Module (TPM): Yes
Memory
Supported RDIMM clock speeds: 4400 MHz, 5200 MHz, 4000, 3600 MHz, 4800 MHz
Supported memory types: DDR5 UDIMM
Number of DIMM slots: 4
Design
On/off switch: Yes
Product colour: Black, Silver
LED indicators: Yes
Chassis type: Rack (1U)
Power
Power supply: 800 W
Redundant power supply: Yes
80 PLUS certification: 80 PLUS Titanium
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Operating temperature (T-T): 10 - 30 °C
Storage relative humidity (H-H): 20 - 95%
Weight & dimensions
Height: 43.5 mm
Depth: 710 mm
Width: 438 mm
Network
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
LAN controller: Broadcom BCM5720
Ethernet LAN data rates: 10,100,1000 Mbit/s
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x4 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Storage
RAID levels: 1, 0, 10
Number of storage drives supported: 2
Supported storage drive types: HDD & SSD
Number of 2.5"/3.5" bays : 4
Supported storage drive interfaces: Serial ATA
Storage drive sizes supported: 3.5", 2.5
Ports & interfaces
Mini DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Port Management LAN: Yes, 1
Safety warning
Warnings: Do not throw into regular trash, product requires special disposal., Do not disassemble the unit yourself., The product may contain components that are harmful to health, use caution when handling.
