Power
DC voltage: 12 V
DC current (max): 1.5 A
Power supply type: DC
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -10 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Width: 197 mm
Height: 41.5 mm
Weight: 540 g
Depth: 204.3 mm
Network
Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; Filtro IP; FTP; DDNS
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Ethernet LAN (RJ-45) ports: 1
Certification: CE-LVD: IEC 62368-1:2014 CE-EMC: EN IEC
61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN
55032:2015+A11:2020, EN 55035:2017+A11:2020, EN
55024:2010+A1:2015, EN 50130-4:2011+A1:2014
Performance
Channels quantity: 4 channels
Maximum video resolution: 1920 x 1080 pixels
Product colour: Black
Video compression formats: H.264, H.264+, H.265+, H.265
Audio formats supported: G.711 A-law, PCM, G.711u
Internal: No
Rack capacity: 1U
Video motion detection: Yes
Operating system installed: Linux
Packaging data
Package depth: 64 mm
Package weight: 940 g
Package height: 240 mm
Package width: 332 mm
Ports & interfaces
BNC input ports: 4
HDMI ports quantity: 1
VGA (D-Sub) output ports: 1
USB 2.0 ports quantity: 2
Hard drive
Maximum HDD capacity: 6 TB
Number of HDDs supported: 1
HDD interface: SATA
