Certification: CE EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014; CE LVD: EN 62368-1:2014; FCC: 47 CFR FCC Part15, SubpartB, Class A 2023-06-15
Features
Product colour: Black
Power
Current: 4 A
Power consumption (typical): 10 W
Power source type: DC
DC output voltage: 12
Operational conditions
Storage relative humidity (H-H): 10 - 93%
Operating temperature (T-T): -10 - 55 °C
Weight & dimensions
Width: 375 mm
Height: 53 mm
Weight: 1.51 kg
Depth: 284.2 mm
Performance
Input bandwidth: 180 / 256 Mbit/s
Output bandwidth: 180 / 256 Mbit/s
Backup function: Yes
Video formats supported: H.265, H.264, H.264+, M-JPEG, H.265+
Video input channels: 16 channels
Total megapixels: 16 MP
Maximum resolution: 4608 x 3472 pixels
People counting function: Yes
Audio
Audio codecs: G.711a, G.711Mu, G.726, PCM
Storage
HDD interface: SATA
Maximum storage capacity: 2 x 16 TB
Ports & interfaces
Number of SATA connectors: 2
Power over Ethernet (PoE): No
USB 2.0 ports quantity: 2
VGA (D-Sub) output ports: 1
HDMI ports quantity: 1
Alarm output channels: 2
Ethernet LAN data rates: 10,100,1000 Mbit/s
Audio RCA outputs: 1
Ethernet LAN (RJ-45) ports: 1
Alarm input channels: 4
RCA input: 1
