Design
Mounting type: Ceiling/wall
Product colour: Grey, Black
Power
DC output voltage: 12
DC output current: 1 A
Power source type: DC
Power consumption (max): 12 W
Security
Human and vehicle targets classification: Yes
Video motion detection: Yes
Security algorithms: WPA, WPA2
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -10 - 55 °C
Management features
Reset button: Yes
Weight & dimensions
Height: 49.2 mm
Diameter: 12.6 cm
Weight: 293 g
Network
Ethernet interface type: Fast Ethernet
Wi-Fi: Yes
Live view: Yes
Supported network protocols: HTTPS, SSL, TCP/IP, UDP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
User access level: Administrator, User
Ethernet LAN: Yes
Number of users: 20 user(s)
Bluetooth: No
Networking standards: IEEE 802.11g, IEEE 802.11a, IEEE 802.11b, IEEE 802.11n
Wi-Fi standards: 802.11g, 802.11b, Wi-Fi 4 (802.11n), 802.11a
System requirements
Mobile operating systems supported: Android, iOS
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Performance
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor
Virtual assistant: Google Assistant
Connectivity technology: Wired & Wireless
Type: IP security camera
Packaging content: 1* Fisheye Series W520
1* 1m Network Cable
1* Power Adapter
1* 4.5m Power Extension Cable
1* Mounting Template
1* Mount Base
1* Pack of Screws
1* Quick Start Guide
1* Surveillance Sticker
Packaging content
Number of cameras: 1
Screws included: Yes
Mounting kit: Yes
Manual: Yes
Audio
Built-in speaker(s): Yes
Built-in microphone: Yes
Audio system: 2-way
Storage
Compatible memory cards: MicroSD (TransFlash)
Built-in HDD: No
Maximum memory card size: 256 GB
Card reader integrated: Yes
Ports & interfaces
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, diagonal: 180°
Lens viewing angle, vertical: 180°
Lens viewing angle, horizontal: 180°
Image sensor
Number of sensors: 1
Optical sensor size: 25.4 / 2.5 mm (1 / 2.5")
Sensor type: CMOS
Video
Video compression formats: H.265
Bit rate: 64 Kbps - 8192 Kbps
Video formats supported: H.265
Video recording: Yes
Frame rate: 25 fps
Total megapixels: 6.5 MP
Video streaming: Yes
Maximum resolution: 2560 x 2560 pixels
Supported graphics resolutions: 2560 x 2560
Night vision
Night vision distance: 8 m
Number of illumination LEDs: 3
LED type: IR
Infra-red wavelength: 850 nm
Night vision: Yes
Lens system
Maximum aperture number: 2
Number of lenses: 1
Fixed focal length: 1.98 mm
