Features
Product colour: Black
Power
Output voltage: 48 - 53 V
Power consumption (typical): 10 W
Power over Ethernet (PoE) power per port: 25 W
Operational conditions
Operating temperature (T-T): -10 - 45 °C
Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
Weight: 1.4 kg
Depth: 230 mm
Width: 260 mm
Height: 41 mm
System requirements
Mac compatibility: Yes
Windows operating systems supported: Yes
Browser supported: Edge, Firefox, Chrome, Safari
Mobile operating systems supported: Android, iOS
Supported resolutions: 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768
Performance
Maximum resolution: 3840 x 2160 pixels
Number of simultaneously playbacked channels: 4 channels
Video formats supported: H.264, H.265
Video motion detection: Yes
Number of users: 20 user(s)
Video recording modes: 1080p, 720p
Video input channels: 8 channels
Wireless LAN features
Wi-Fi: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 9
Networking standards: IEEE 802.3at, IEEE 802.3af
Ethernet WAN: Yes
Power over Ethernet (PoE): Yes
Ethernet LAN data rates: 10, 100
HDMI ports quantity: 1
USB 2.0 ports quantity: 2
VGA (D-Sub) output ports: 1
HDMI output: Yes
Audio RCA outputs: 1
Supported network protocols: HTTPS, TCP/IP, UDP, DHCP, P2P, UPNP, RTMP, SMTP, SSL/TLS, DNS, DDNS, NTP
Power over Ethernet (PoE) ports quantity: 8
eSATA: Yes
Hard drive
HDD interface: eSATA, SATA
Maximum storage capacity: 12 TB
Number of HDDs supported: 2
