Design
International Protection (IP) code: IP66
LED indicators: Yes
Form factor: Dome
Mounting type: Ceiling
Product colour: White
Power
Power consumption (max): 12 W
DC output current: 1 A
Power source type: DC, PoE
DC output voltage: 12, 48
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Reset button: Yes
Weight & dimensions
Height: 103.8 mm
Diameter: 11.7 cm
Weight: 526 g
Network
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Bluetooth: No
Supported network protocols: HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
User access level: Administrator, User
Wi-Fi: No
Number of users: 20 user(s)
Networking standards: IEEE 802.3af
System requirements
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Mobile operating systems supported: Android, iOS
Performance
Connectivity technology: Wired
Placement supported: Indoor & outdoor
Virtual assistant: Google Assistant
Type: IP security camera
Packaging data
Package height: 145 mm
Package width: 159 mm
Package weight: 1.13 kg
Package depth: 262 mm
Packaging content
Mounting kit: Yes
Number of cameras: 1
Screws included: Yes
Cables included: LAN (RJ-45)
Audio
Built-in speaker(s): Yes
Audio system: 2-way
Built-in microphone: Yes
Bit rate range: 64 - 8192 Kbit/s
Storage
Built-in HDD: No
Maximum memory card size: 256 GB
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Camera
Lens viewing angle, vertical: 56°
Lens viewing angle, horizontal: 105°
Image sensor
Optical sensor size: 25.4 / 2.49 mm (1 / 2.49")
Number of sensors: 1
Sensor type: CMOS
Video
Total megapixels: 8 MP
Frame rate: 25 fps
Video compression formats: H.265
Maximum resolution: 3840 x 2160 pixels
Night vision
Infra-red wavelength: 850 nm
Night vision distance: 30 m
LED type: IR
Number of illumination LEDs: 2
Night vision: Yes
Lens system
Maximum aperture number: 1.6
Fixed focal length: 2.8 mm
