Design
Form factor: Dome
Product colour: Black, White
Mounting type: Ceiling/wall
Protection features: Weatherproof
Power
DC output voltage: 12, 48
DC output current: 2 A
Power consumption (max): 12 W
Power source type: DC, PoE
Operational conditions
Operating temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Reset button: Yes
Weight & dimensions
Weight: 1.21 kg
Height: 129 mm
Depth: 147 mm
Width: 228.2 mm
Network
User access level: Administrator, User
Number of users: 20 user(s)
Ethernet LAN: Yes
Supported network protocols: HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Bluetooth: No
Networking standards: IEEE 802.1af
Wi-Fi: No
System requirements
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Mobile operating systems supported: iOS, Android
Performance
Colour temperature: 6500 K
Day/night mode: Yes
Connectivity technology: Wired
Luminous flux: 450 lm
Placement supported: Indoor & outdoor
Built-in light: Yes
Type: IP security camera
Packaging data
Package width: 205 mm
Package weight: 1.76 kg
Package height: 190 mm
Package depth: 270 mm
Packaging content
Mounting kit: Yes
Cables included: LAN (RJ-45)
Screws included: Yes
Number of cameras: 1
Audio
Built-in speaker(s): Yes
Audio system: 2-way
Built-in microphone: Yes
Storage
Maximum memory card size: 256 GB
Compatible memory cards: MicroSD (TransFlash)
Card reader integrated: Yes
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Tilt angle range: 0 - 90°
Camera tilt control: Yes
Pan range: 0 - 355°
Camera pan control: Yes
Tilt speed: 60 °/sec
Pan speed: 90 °/sec
Image sensor
Number of sensors: 2
Sensor type: CMOS
Optical sensor size: 25.4 / 3 mm (1 / 3")
Video
Video recording: Yes
Supported video modes: 2160p
Video compression formats: H.264, H.265
Frame rate: 25 fps
Total megapixels: 8 MP
Supported graphics resolutions: 3840 x 2160
Maximum resolution: 3840 x 2160 pixels
Night vision
Infra-red wavelength: 850 nm
Number of illumination LEDs: 2
Night vision: Yes
Night vision distance: 30 m
LED type: IR
Lens system
Maximum aperture number: 1.6
Safety warning
Warnings: Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling., The product contains electronic components; do not dispose of with the normal household waste.
