Design
International Protection (IP) code: IP67
Form factor: Dome
Weatherproof: Yes
Mounting type: Wall
Product colour: White
Power
Power consumption (max): 12 W
DC output voltage: 12
DC output current: 1 A
Power source type: DC
Security
Video motion detection: Yes
Security algorithms: WPA, WPA2, WPA3
Intelligent Video Surveillance (IVS) system features: Vehicle detection, Pet detection, Human detection
Built-in siren: Yes
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -10 - 55 °C
Management features
Reset button: Yes
Weight & dimensions
Weight: 863 g
Width: 238 mm
Depth: 72 mm
Height: 80 mm
Network
Wi-Fi standards: 802.11b, Wi-Fi 4 (802.11n), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac)
Number of users: 20 user(s)
Ethernet interface type: Fast Ethernet
Networking standards: IEEE 802.11ax, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11a
Ethernet LAN: Yes
Wi-Fi: Yes
Supported network protocols: HTTPS, SSL, TCP/IP, UDP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Bluetooth: No
Live view: Yes
User access level: Administrator, User
System requirements
Mobile operating systems supported: iOS, Android
Mac operating systems supported: Yes
Windows operating systems supported: Yes
Performance
Luminous flux: 450 lm
Connectivity technology: Wired & Wireless
Built-in light: Yes
Colour temperature: 6500 K
Day/night mode: Yes
Type: IP security camera
Placement supported: Outdoor
Virtual assistant: Google Assistant
Packaging content: 1* W430
1* Power Adapter
1* 1m Network Cable
1* 4.5m Power Extension Cable
1* Quick Start Guide
1* Surveillance Sticker
1* Mounting Template
1* Pack of Screws
1* Wrench
1* Waterproof Lid
Packaging content
Number of cameras: 1
Mounting kit: Yes
Screws included: Yes
Audio
Audio system: 2-way
Built-in speaker(s): Yes
Built-in microphone: Yes
Storage
Built-in HDD: No
Maximum memory card size: 256 GB
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Camera
Lens viewing angle, horizontal: 31 - 700°
Lens viewing angle, vertical: 17 - 55°
Image sensor
Number of sensors: 1
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Sensor type: CMOS
Video
Supported video modes: 2160p
Supported graphics resolutions: 3840 x 2160
Bit rate: 64Kbps - 6144Kbps
Total megapixels: 8 MP
Maximum resolution: 3840 x 2160 pixels
Video compression formats: H.265
Frame rate: 15 fps
Video formats supported: H.265
Video recording: Yes
Night vision
LED type: IR
Number of illumination LEDs: 5
Infra-red wavelength: 850 nm
Night vision: Yes
Night vision distance: 30 m
Lens system
Focal length range: 2.7 - 13.5 mm
Zoom capability: Yes
Maximum aperture number: 1.6
Optical zoom: 5x
Number of lenses: 1
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
