Design
Control type: Touch
Display diagonal: 10.9 cm (4.3")
Built-in display: Yes
Product colour: Black, Grey
Scanner type: ADF + Manual feed scanner
Touchscreen: Yes
Power
Sleep mode: Yes
Power supply type: AC
Power consumption (sleep): 1.9 W
Power consumption (standby): 0.15 W
AC input frequency: 50/60 Hz
Input voltage: 100 - 240 V
Power consumption (typical): 19 W
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Height: 143 mm
Weight: 3.1 kg
Depth: 157 mm
Width: 292 mm
Network
Ethernet LAN: Yes
System requirements
Windows operating systems supported: Windows 11, Windows 10
Server operating systems supported: Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2022, Windows Server 2019
Performance
Scan drivers: TWAIN, SANE, ISIS
Sensor type: Dual CIS
Ultrasonic sensor: Yes
Scanner smart software features: Background purifying, Blank page detection
Daily duty cycle (max): 6000 pages
Light source: RGB LED
Packaging data
Package width: 249 mm
Package depth: 399 mm
Package weight: 4.5 kg
Package height: 240 mm
Packaging content: ADF paper chute, AC adapter, Setup DVD-ROM
Packaging content
Cables included: AC, USB
AC adapter included: Yes
Ports & interfaces
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
Socket connector type: C7
USB port: Yes
Other features
Background colours: White
Compliance certificates: RoHS
Logistics data
Products per pallet (sea): 96 pc(s)
Wood packaging weight: 0 g
Harmonized System (HS) code: 8471607000
Pallet height (air): 130.4 cm
Plastic packaging weight: 15 g
Metal packaging weight: 0 g
Products per pallet (air): 60 pc(s)
Paper packaging weight: 2.4 kg
Pallet height (sea): 199 cm
Foil packaging weight: 15 g
Glass packaging weight: 0 g
Polystyrene (EPS/EPP) packaging weight: 200 g
Cardboard packaging weight: 1.2 kg
Input capacity
Auto document feeder (ADF) input capacity: 50 sheets
Paper handling
Maximum ISO A-series paper size: A4
Card thickness (max): 0.76 mm
ISO A-series sizes (A0...A9): A5, A4, A6
Paper tray media weight: 40 - 209 g/m²
ISO B-series sizes (B0...B9): B5, B6
Letter: Yes
Scanning media types supported: Plastic Card, Plain paper, Business Card, Post Card(JPN)
Long-paper mode: Yes
Legal: Yes
Scanning
Output monochrome depth: 8 bit
ADF scan speed (colour, A4): 40 ppm
Maximum scan size: 210 x 297 mm
Output colour depth: 24 bit
Duplex scanning: Yes
Duplex ADF scan speed (b/w, A4): 80 ipm
Optical scanning resolution: 600 x 600 DPI
Safety warning
Warnings: Do not use in damp areas., Avoid exposure to extreme temperatures., Do not open the housing of the unit to avoid electric shock.
Sustainability
Sustainability compliance: Yes
Sustainability certificates: ENERGY STAR
