Design
Control type: Buttons
Built-in display: Yes
Scanner type: ADF + Manual feed scanner
Product colour: Black, Grey
Power
Power supply type: AC
Power consumption (standby): 0.2 W
Sleep mode: Yes
AC input frequency: 50 - 60 Hz
Power consumption (typical): 28 W
Input voltage: 100 - 240 V
Weight & dimensions
Depth: 234 mm
Weight: 8.8 kg
Height: 300 mm
Width: 577 mm
Network
Ethernet LAN: Yes
Performance
Sensor type: Dual CIS/CCD
Scan drivers: TWAIN, ISIS
Scan file formats: JPEG, PNG, TIFF, PDF
Light source: LED
Scanner smart software features: Blank page detection
Packaging data
Package height: 375 mm
Package width: 500 mm
Package depth: 700 mm
Package weight: 13 kg
Packaging content
AC adapter included: Yes
Cables included: AC
Ports & interfaces
USB version: 3.2 Gen 1 (3.1 Gen 1)
Socket connector type: C5
USB port: Yes
USB connector type: USB Type-B
Other features
Compliance certificates: RoHS
Logistics data
Products per pallet (air): 12 pc(s)
Pallet height (air): 124.5 cm
Pallet height (sea): 199.5 cm
Products per pallet (sea): 20 pc(s)
Harmonized System (HS) code: 8471607000
Paper packaging weight: 2.4 kg
Metal packaging weight: 0 g
Wood packaging weight: 0 g
Plastic packaging weight: 15 g
Polystyrene (EPS/EPP) packaging weight: 200 g
Cardboard packaging weight: 1.2 kg
Foil packaging weight: 15 g
Glass packaging weight: 0 g
Input capacity
Auto document feeder (ADF) input capacity: 100 sheets
Paper handling
Legal: Yes
ISO A-series sizes (A0...A9): A4, A5, A6
Letter: Yes
Paper tray media weight: 20 - 465 g/m²
ISO B-series sizes (B0...B9): B6, B5
Card thickness (max): 1.4 mm
Maximum ISO A-series paper size: A4
ID-cards (ISO/IEC 7810) compliant: Yes
Scanning media types supported: Business Card, Post Card(JPN)
Scanning
Black/white scanning colour modes: Monochrome, Grayscale
ADF scan speed (b/w, A4): 70 ppm
Duplex scanning: Yes
Duplex ADF scan speed (b/w, A4): 140 ipm
Maximum scan size: 216 x 355.6 mm
Optical scanning resolution: 600 x 600 DPI
Safety warning
Warnings: Do not open the housing of the unit to avoid electric shock., Avoid exposure to extreme temperatures., Do not use in damp areas.
Sustainability
Sustainability certificates: ENERGY STAR
