Design
Control type: Touch
Display size (HxV): 109 x 65 mm
Colour display: Yes
Touchscreen: Yes
Product colour: Black
Display diagonal: 12.7 cm (5")
Built-in display: Yes
Scanner type: ADF scanner
Power
Sleep mode: Yes
Power consumption (sleep): 1.4 W
Power supply type: AC
Power consumption (standby): 0.2 W
Input voltage: 100 - 240 V
Power consumption (typical): 17 W
AC input frequency: 50/60 Hz
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Weight: 3.5 kg
Width: 292 mm
Height: 159 mm
Depth: 161 mm
Network
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11g, 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n)
Security algorithms: WPA2-PSK, WPA, WPA3-Personal, WPA-PSK, WPA2, WPA2-AES, WPA2-EAP, WPA-TKIP, WPA-AES
Wi-Fi: Yes
Performance
Ultrasonic sensor: Yes
Sensor type: Dual CIS
Scan file formats: JPEG, PDF
Scan to: Cloud, E-mail
Light source: RGB LED
Ports & interfaces
USB version: 3.2 Gen 1 (3.1 Gen 1)
USB port: Yes
USB connector type: USB Type-C
Other features
Compliance certificates: RoHS
Input capacity
Auto document feeder (ADF) input capacity: 100 sheets
Paper handling
ISO B-series sizes (B0...B9): B6, B4, B5
Multi feed detection: Yes
Maximum ISO A-series paper size: A4
Paper tray media weight: 40 - 209 g/m²
ISO A-series sizes (A0...A9): A3, A4, A5, A6
Scanning media types supported: Photo paper, Business Card, Plain paper, Post Card(JPN)
Long-paper mode: Yes
Letter: Yes
Legal: Yes
Scanning
ADF scan speed (b/w, A4): 45 ppm
Duplex scanning: Yes
Maximum scan size: 297 x 432 mm
Optical scanning resolution: 600 x 600 DPI
Duplex ADF scan speed (b/w, A4): 90 ipm
Colour scanning: Yes
Sustainability
Sustainability certificates: ENERGY STAR
