Features
Flash memory: 128 MB
Internal memory: 256 MB
Built-in processor: Yes
Design
Product colour: White
Product type: Tabletop router
Power
Power source type: DC
Output voltage: 12 V
Output current: 1 A
External power adapter: Yes
Security
Security algorithms: WPA, WPA3, WPA2
Operational conditions
Operating temperature (T-T): -10 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Management features
Reset button: Yes
Cloud-managed: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 500 g
Depth: 140 mm
Height: 30 mm
Width: 260 mm
Receiver sensitivity: 2.4 GHz:20MHz
802.11b: -91 dBm(1 Mbps)
802.11g: -91 dBm(6 Mbps), -72 dBm(54 Mbps)
802.11n: -90dBm(MCS0), -70 dBm(MCS7)
5 GHz:20MHz
802.11n: -85 dBm(MCS0), -67 dBm(MCS7)
802.11a: -89 dBm(6 Mbps), -72 dBm(54 Mbps)
802.11ac: -90dBm(MCS0), -63dBm(MCS8)
802.11ax: -88dBm(MCS0), -62dBm(MCS8), -58dBm(MCS11)
Network
PPPoE/PPTP/L2TP pass-through: Yes
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Flow control support: Yes
Ethernet LAN interface type: Gigabit Ethernet
Dynamic DNS (DDNS): Yes
Ethernet LAN: Yes
Packaging content
Quick start guide: Yes
AC adapter included: Yes
Warranty card: Yes
Cables included: LAN (RJ-45)
Wireless LAN features
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11b
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (max): 2976 Mbit/s
WLAN data transfer rate (second band): 2402 Mbit/s
WLAN data transfer rate (first band): 574 Mbit/s
Protocols
DHCP client: Yes
Universal Plug and Play (UPnP): Yes
DHCP server: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 3
DC-in jack: Yes
USB port: No
Antenna
Antenna design: External
Antennas quantity: 5
Antenna gain level (max): 5 dBi
Antenna direction type: Omni-directional
WAN connection
Ethernet WAN: Yes
WAN connection type: RJ-45
Logistics data
Warranty period: 3 year(s)
