Features
Ethernet LAN data rates: 10, 1000 Mbit/s, 100
Maximum data transfer rate (5 GHz): 2402 Mbit/s
Networking standards: IEEE 802. 11n, IEEE 802.11ax, IEEE 802.11ac Wave 2/Wave1
Number of users: 512 user(s)
2.4 GHz: Yes
Modulation: DBPSK, OFDM, 1024QAM OFDMA, MIMO-OFDM, 64-QAM, DSSS, 16-QAM, BPSK, 256-QAM, CCK, QPSK, DQPSK
VLAN support: Yes
Frequency band: 2.4 - 5.35 GHz
Maximum data transfer rate (2.4 GHz): 800 Mbit/s
MIMO: Yes
Maximum data transfer rate: 2402 Mbit/s
Wi-Fi roaming: Yes
5 GHz: Yes
Design
Placement: Ceiling
Product colour: White
LED indicators: Power
Power
Power consumption (typical): 25.4 W
Power over Ethernet (PoE): Yes
Input current: 1.5 A
Security
Security algorithms: WPA-TKIP, WPA2-AES, WPA-PSK
Number of SSID supported: 8
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Weight: 1.05 kg
Depth: 35 mm
Width: 220 mm
Height: 220 mm
Protocols
Supported network protocols: 802.11ax, 802.11ac Wave 2/Wave1, 802. 11n, 802.11a/b/g
DHCP client: Yes
DHCP server: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
DC-in jack: Yes
Antenna
Antenna gain level (max): 3 dBi
Antenna features: Integrated antenna
Antenna type: Internal
Antennas quantity: 2
