Features
Wireless isolation: Yes
Modulation: OFDM, 256-QAM, 16-QAM, BPSK, 64-QAM, DSSS, CCK, 1024-QAM, QPSK, DBPSK, DQPSK
Number of users: 512 user(s)
Maximum data transfer rate (5 GHz): 1201 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
VLAN support: Yes
Wi-Fi roaming: Yes
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Networking standards: IEEE 802.11ax, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.11a, IEEE 802.11b
Frequency band: 2.4 - 5.35 GHz
Ethernet LAN data rates: 1000 Mbit/s, 10, 100
Maximum data transfer rate: 1201 Mbit/s
2.4 GHz: Yes
MIMO: Yes
5 GHz: Yes
Design
Placement: Wall
LED indicators: Power
Product colour: White
Power
Power over Ethernet (PoE): Yes
Input current: 1.5 A
Power consumption (typical): 15.3 W
Security
Whitelist: Yes
Service Set Identifier (SSID) features: Hidden SSID, Multiple SSIDs
Number of SSID supported: 8
Security algorithms: WPA-TKIP, WPA-PSK, WPA, WPA2-AES
Blacklist: Yes
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Management features
Web-based management: Yes
Weight & dimensions
Weight: 560 g
Height: 194 mm
Depth: 35 mm
Width: 194 mm
Packaging content
Quantity per pack: 1 pc(s)
Supported protocols: Concurrent 802.11ax, 802.11ac wave2/wave1, 802.11a/b/g/n
Protocols
DHCP server: Yes
DHCP client: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
DC-in jack: Yes
Antenna
Antenna features: Integrated antenna
Antennas quantity: 2
Antenna gain level (max): 3 dBi
Antenna type: Internal
