Receiver sensitivity: 11b: -91dBm(1Mbps), -88dBm(5.5Mbps),-
85dBm(11Mbps)
11a/g: -89dBm(6Mbps), -80dBm(24Mbps), -
76dBm(36Mbps)，-71dBm(54Mbps)
11n: -83dBm(MCS0)，-65dBm(MCS7)，-
83dBm(MCS8)，-65dBm(MCS15)
11ac: 20MHz: -83dBm(MCS0), -57dBm(MCS9)
11ac: 40MHz: -79dBm(MCS0), -57dBm(MCS9)
11ac: 80MHz: -76dBm(MCS0), -51dBm(MCS9)
11ax: 20MHz: -85dBm(MCS0), -58dBm(MCS11)
11ax: 40MHz: -82dBm(MCS0), -54dBm(MCS11)
11ax: 80MHz: -79dBm(MCS0), -52dBm(MCS11)
Features
Ethernet LAN data rates: 100, 10, 1000 Mbit/s
5 GHz: Yes
Maximum data transfer rate: 2974 Mbit/s
2.4 GHz: Yes
Frequency band: 2.4 - 5 GHz
MIMO: Yes
Networking standards: IEEE 802.11k, IEEE 802.1x, IEEE 802.11ax, IEEE 802.11g, IEEE 802.11n, IEEE 802.11b, IEEE 802.11a, IEEE 802.3at, IEEE 802.11ac, IEEE 802.3af, IEEE 802.11r
Spread spectrum method: OFDMA
Maximum data transfer rate (2.4 GHz): 573 Mbit/s
Wi-Fi Multimedia (WMM)/(WME): Yes
Wi-Fi roaming: Yes
MIMO type: Multi User MIMO
VLAN support: Yes
Number of users: 512 user(s)
Maximum data transfer rate (5 GHz): 2401 Mbit/s
Design
Product colour: White
Reset button: Yes
LED indicators: System
International Protection (IP) code: IP65
Placement: Pole, Wall
Power
Power over Ethernet (PoE): Yes
Power consumption (typical): 16 W
Security
IP Source Guard (IPSG): Yes
Security algorithms: WPA-PSK, WPA3-SAE, WPA-TKIP, WPA2-AES, OWE, WPA2-PSK
Number of SSID supported: 8
Blacklist: Yes
DHCP snooping: Yes
Whitelist: Yes
Operational conditions
Operating temperature (T-T): -30 - 65 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 75 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Weight: 400 g
Depth: 70 mm
Height: 35 mm
Width: 200 mm
Performance
Internal memory: 512 MB
Flash memory: 128 MB
Packaging content
Quantity per pack: 1 pc(s)
Antenna included: Yes
Protocols
DHCP server: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DC-in jack: No
Antenna
Antenna type: Internal
Antenna direction type: Omni-directional
Antenna gain level (max): 6.5 dBi
