Receiver sensitivity: 11b: -91dBm(1Mbps)，-88dBm(5.5Mbps)，-
85dBm(11Mbps)
11a/g: -89dBm(6Mbps)，-80dBm(24Mbps)，-
76dBm(36Mbps)，-71dBm(54Mbps)
11n: -83dBm(MCS0)，-65dBm(MCS7)，-
83dBm(MCS8)，-65dBm(MCS15)
11ac: 20MHz: -83dBm(MCS0), -57dBm(MCS9)
11ac: 40MHz: -79dBm(MCS0), -57dBm(MCS9)
11ac: 80MHz: -76dBm(MCS0), -51dBm(MCS9)
11ac: 160MHz: -76dBm(MCS0), -50dBm(MCS9)
11ax: 20MHz: -85dBm(MCS0), -58dBm(MCS11)
11ax: 40MHz: -82dBm(MCS0), -54dBm(MCS11)
11ax: 80MHz: -79dBm(MCS0), -52dBm(MCS11)
11ax: 160MHz: -76dBm(MCS0), -49dBm(MCS11)
11be: 20MHz: –85dBm(MCS0), –52dBm(MCS13)
11be: 40MHz: –82dBm(MCS0), –49dBm(MCS13)
11be: 80MHz: –82dBm(MCS0), –46dBm(MCS13)
11be: 160MHz: –79dBm(MCS0), –44dBm(MCS13)
Features
Ethernet LAN data rates: 10, 1000 Mbit/s, 2500 Mbit/s, 100
5 GHz: Yes
Maximum data transfer rate (2.4 GHz): 688 Mbit/s
2.4 GHz: Yes
Number of users: 511 user(s)
Maximum data transfer rate: 5011 Mbit/s
Networking standards: IEEE 802.11ax, IEEE 802.3af, IEEE 802.1x, IEEE 802.11k, IEEE 802.11ac, IEEE 802.3at, IEEE 802.11be, IEEE 802.11r, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11b
Wi-Fi Multimedia (WMM)/(WME): Yes
MIMO: Yes
MIMO type: Multi User MIMO
Spread spectrum method: OFDMA
Maximum data transfer rate (5 GHz): 4323 Mbit/s
Design
International Protection (IP) code: IP41
Placement: Ceiling, Wall
Reset button: Yes
Product colour: White
LED indicators: System
Power
Power consumption (max): 30 W
DC voltage range: 12 V
Power over Ethernet (PoE): Yes
Input current: 2.5 A
Security
Security algorithms: WPA3-SAE, OWE, WPA-PSK, WPA2-AES, WPA2-PSK, WPA-TKIP
Number of SSID supported: 8
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Weight: 650 g
Width: 208 mm
Height: 40 mm
Depth: 208 mm
Performance
Internal memory: 512 MB
Flash memory: 256 MB
Packaging content
Quantity per pack: 1 pc(s)
Certificates
Compliance certificates: RoHS, CE, ISED, cTUVus, Federal Communications Commission (FCC)
Protocols
DHCP server: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes
Antenna
Antenna direction type: Omni-directional
Antenna type: Internal
Antenna gain level (max): 3 dBi
