Processor
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor socket: Socket AM5
Graphics
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 11, Windows 10 x64
Motherboard chipset: AMD B850
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Product colour: White
Audio chip: Realtek ALC897
Motherboard chipset family: AMD
Memory
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 8000 MHz
Maximum internal memory per slot: 64 GB
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Bluetooth: Yes
Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11b
Wi-Fi: Yes
Bluetooth version: 5.4
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
LAN controller: Dragon RTL8125BG
Internal I/O
Number of SATA III connectors: 4
Number of chassis fan connectors: 3
RGB LED pin header: Yes
12V power connector: Yes
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Serial port headers: 1
CPU fan connector: Yes
Front panel connector: Yes
Audio connector: Yes
USB 2.0 connectors: 1
Number of RGB LED pin headers: 3
Number of CPU fan connectors: 1
Number of water pump connectors: 1
Packaging content
Antenna included: Yes
Storage controllers
Number of storage drives supported: 7
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
HDMI ports quantity: 1
USB connector type: USB Type-A, USB Type-C
WiFi-AP antenna jack: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Microphone in: Yes
Line-in: Yes
USB 2.0 ports quantity: 4
Headphone outputs: 6
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x4 (Gen 4.x) slots: 1
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 2280
2nd M.2 largest key size: 2280
1st M.2 largest key size: 2280
3rd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
