Features Mean time between failures (MTBF): 2500000 h HDD size: 3.5" Type: HDD Start/stop cycles: 600000 HDD sustained transfer rate: 260 MiB/s Recording technology: CMR HDD capacity: 12 TB Storage drive buffer size: 512 MB HDD speed: 7200 RPM Interface: Serial ATA III Number of AI channels: 32 Component for: Surveillance system HDD interface transfer rate: 6 Gbit/s Rotational Vibration (RV) sensors: Yes
Power Power consumption (idle): 6.3 W Power consumption (typical): 7.8 W Operating voltage: 5 / 12 V Start-up current: 2 A Power consumption (standby): 1.1 W
Operational conditions Operating temperature (T-T): 0 - 65 °C
Weight & dimensions Weight: 685 g Depth: 147 mm Height: 26.1 mm Width: 101.8 mm
Other features Maximum number of cameras supported: 64
Logistics data Harmonized System (HS) code: 84717050 Products per pallet layer: 8 pc(s)
