Features Number of AI channels: 32 HDD sustained transfer rate: 229 MiB/s HDD capacity: 16 TB HDD size: 3.5" Storage drive buffer size: 512 MB Component for: Surveillance system HDD interface transfer rate: 6 Gbit/s Start/stop cycles: 600000 Interface: Serial ATA III Type: HDD HDD speed: 7200 RPM Mean time between failures (MTBF): 2000000 h Rotational Vibration (RV) sensors: Yes
Power Power consumption (idle): 1.2 W Power consumption (max): 8.2 W Operating voltage: 5 / 12 V Power consumption (standby): 1.2 W Start-up current: 2 A Power consumption (typical): 6.7 W
Operational conditions Operating temperature (T-T): 0 - 65 °C
Weight & dimensions Height: 26.1 mm Depth: 147 mm Weight: 695 g Width: 101.8 mm
Other features Maximum number of cameras supported: 64
Safety warning Warnings: Do not expose to high temperatures or moisture., Do not open or disassemble., Do not drop and avoid strong impacts.
