Design Cooling type: Active On/off switch: Yes Product colour: Black Fan diameter: 12 cm Number of fans: 1 fan(s)
Power Input current: 10 A AC input voltage: 100 - 240 V Combined power (+5Vsb): 12.5 W Max output current (+5V): 20 A Max output current (+5Vsb): 2.5 A Combined power (-12V): 3.6 W Max output current (+12V): 70 A Combined power (+3.3V): 100 W Combined power (+12V): 840 W Total power: 850 W Max output current (-12V): 0.3 A Power protection features: Over current, Short circuit, Over voltage Max output current (+3.3V): 20 A Combined power (+5V): 100 W
Operational conditions Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Depth: 140 mm Height: 86 mm Width: 150 mm
Performance 80 PLUS certification: 80 PLUS Gold Mean time between failures (MTBF): 100000 h Bearing technology: Sleeve Purpose: PC Power supply unit (PSU) form factor: ATX
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 3 Number of SATA power connectors: 6 PCI Express power connectors (6+2 pin): 2 Peripheral (Molex) power cable length: 690 mm CPU power cable length: 60 cm Motherboard power cable length: 55 cm Cabling type: Semi-Modular PCI Express power cable length: 70 cm Motherboard power connector: 20+4 pin ATX CPU power connector (4+4 pin): Yes
