Technical details
Sustainability certificates: ENERGY STAR
Design
Cooling type: Active
On/off switch: Yes
Number of fans: 1 fan(s)
Fan diameter: 13.5 cm
Product colour: White
Power
Maximum input current (@220V): 5.5 A
Max output current (-12V): 0.3 A
Combined power (+3.3V): 100 W
Max output current (+12V): 70 A
Power protection features: Overheating, Over power, Under voltage, Over current, Short circuit, Over voltage
Combined power (-12V): 3.6 W
Combined power (+5V): 100 W
Input current: 11 - 5.5 A
Combined power (+5Vsb): 15 W
AC input voltage: 100 - 240 V
Max output current (+5Vsb): 3 A
Maximum input current (@110V): 11 A
Total power: 850 W
Combined power (+12V): 840 W
Max output current (+5V): 20 A
Max output current (+3.3V): 20 A
AC input frequency: 50/60 Hz
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Height: 86 mm
Depth: 140 mm
Width: 150 mm
Performance
Purpose: PC
Bearing technology: FDB
80 PLUS certification: 80 PLUS Gold
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: ATX
Packaging data
Package type: Box
Certificates
Compliance certificates: RoHS, CE, WEEE, cTUVus, CB, EAC, REACH
Ports & interfaces
Peripheral (Molex) power cable length: 690 mm
CPU power cable length: 70 cm
SATA power cable length: 550
Peripheral (Molex) power connectors (4-pin): 3
PCI Express power connectors (6+2 pin): 3
Motherboard power cable length: 61 cm
Number of SATA power connectors: 2
Cabling type: Fully-Modular
CPU power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (12+4 pin): 1
Logistics data
Warranty period: 10 year(s)
Safety regulation & standards
Safety: cTUVus, TUV, CB, CCC, BSMI, EAC, CE
