Design
Product colour: Black
Fan diameter: 9.2 cm
On/off switch: Yes
Cooling type: Active
Number of fans: 1 fan(s)
Power
AC input frequency: 50 - 60 Hz
Max output current (+5Vsb): 3 A
AC input voltage: 100 - 240 V
Input current: 10 - 5 A
Combined power (+5Vsb): 15 W
Power protection features: Short circuit, Over voltage, Over current
Combined power (+12V): 744 W
Combined power (+5V): 130 W
Max output current (+3.3V): 20 A
Combined power (+3.3V): 130 W
Combined power (-12V): 3.6 W
Max output current (+12V): 62 A
Max output current (+5V): 20 A
Max output current (-12V): 0.3 A
Total power: 750 W
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Depth: 100 mm
Width: 125 mm
Height: 63.5 mm
Performance
80 PLUS certification: 80 PLUS Platinum
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: CFX
Bearing technology: FDB
Purpose: PC
Packaging data
Package type: Box
Packaging content
Cables included: AC, PCIe, Peripheral (Molex), Peripheral (Molex) to SATA 3.3, SATA
Cable tie(s) included: Yes
Ports & interfaces
Motherboard power cable length: 35 cm
PCI Express power connectors (8-pin): 4
Peripheral (Molex) power connectors (4-pin): 3
Motherboard power connector: 20+4 pin ATX
Cabling type: Fully-Modular
Number of SATA power connectors: 6
Safety warning
Warnings: Avoid contact of the product with water or other liquids., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations., Do not open the case - risk of electric shock.
Hazard pictogram(s): GHS07: Harmful, GHS09: Environmental hazard, GHS02: Flammable
