Design On/off switch: Yes Product colour: Black Cooling type: Active Fan diameter: 12 cm Number of fans: 1 fan(s)
Power Power protection features: Short circuit, Over voltage, Over current Total power: 750 W AC input voltage: 100 - 240 V Input current: 10 A AC input frequency: 50 - 60 Hz Combined power (+3.3V): 100 W Max output current (+12V): 62 A Max output current (+5Vsb): 2.5 A Combined power (+5V): 100 W Max output current (+3.3V): 20 A Combined power (-12V): 3.6 W Combined power (+12V): 744 W Max output current (+5V): 20 A Combined power (+5Vsb): 12.5 W Max output current (-12V): 0.3 A
Operational conditions Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Depth: 140 mm Height: 86 mm Width: 150 mm
Performance 80 PLUS certification: 80 PLUS Gold Purpose: PC Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h Bearing technology: Sleeve
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 3 Motherboard power cable length: 55 cm Number of SATA power connectors: 6 PCI Express power connectors (6+2 pin): 2 Peripheral (Molex) power cable length: 690 mm Cabling type: Semi-Modular PCI Express power cable length: 70 cm CPU power cable length: 60 cm CPU power connector (4+4 pin): Yes Motherboard power connector: 20+4 pin ATX
