Seasonic G12 GM power supply unit 650 W 20+4 pin ATX ATX Black

Design
On/off switch: Yes
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Cooling type: Active
Product colour: Black

Power
Max output current (+3.3V): 20 A
Combined power (+5V): 100 W
Total power: 650 W
Combined power (+3.3V): 100 W
Max output current (+5Vsb): 2.5 A
Combined power (+5Vsb): 12.5 W
Combined power (-12V): 3.6 W
Max output current (+12V): 45 A
Max output current (-12V): 3.6 A
Combined power (+12V): 648 W
Max output current (+5V): 20 A
Power protection features: Over current, Short circuit, Over voltage
AC input frequency: 50/60 Hz
Input current: 10 A
AC input voltage: 100 - 240 V

Operational conditions
Operating temperature (T-T): 0 - 50 °C

Weight & dimensions
Width: 150 mm
Height: 86 mm
Depth: 140 mm

Performance
Bearing technology: Sleeve
Power supply unit (PSU) form factor: ATX
Purpose: PC
80 PLUS certification: 80 PLUS Gold
Mean time between failures (MTBF): 100000 h

Packaging data
Package type: Box

Packaging content
Cable tie(s) included: Yes
Cables included: AC, PCIe, Peripheral (Molex), SATA

Certificates
Compliance certificates: RoHS, CE

Ports & interfaces
PCI Express power cable length: 70 cm
Peripheral (Molex) power cable length: 690 mm
Number of SATA power connectors: 6
Motherboard power cable length: 55 cm
Peripheral (Molex) power connectors (4-pin): 3
PCI Express power connectors (6+2 pin): 2
Cabling type: Semi-Modular
Motherboard power connector: 20+4 pin ATX

Logistics data
Warranty period: 5 year(s)
