Design
Fan diameter: 12 cm
Cooling type: Active
Product colour: Black
Number of fans: 1 fan(s)
On/off switch: Yes
Power
Power protection features: Over power, Short circuit, Over voltage, Over total voltage, Under voltage, Over current
Combined power (+5Vsb): 12.5 W
Combined power (-12V): 3.6 W
Input current: 8 A
Total power: 850 W
Max output current (+3.3V): 20 A
AC input voltage: 100 - 240 V
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 2.5 A
Efficiency: 90%
Max output current (+12V): 70 A
Combined power (+3.3V): 100 W
AC input frequency: 50/60 Hz
Combined power (+12V): 840 W
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Width: 150 mm
Height: 86 mm
Depth: 140 mm
Performance
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
Purpose: PC
Packaging data
Package type: Box
Packaging content
Cables included: AC, CPU, PCIe, SATA
Certification: cTUVus, TUV, CB, CCC, BSMI, CE, FCC
Certificates
Compliance certificates: RoHS, WEEE, REACH
Ports & interfaces
Cabling type: Non-Modular
