Design
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Cooling type: Active
Product colour: Black
On/off switch: Yes
Power
Power protection features: Over total voltage, Over power, Short circuit, Over voltage, Under voltage, Over current
Combined power (+3.3V): 100 W
Total power: 650 W
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Input current: 9 A
Max output current (-12V): 0.3 A
Combined power (+5Vsb): 15 W
Combined power (+12V): 648 W
Combined power (-12V): 3.6 W
Max output current (+3.3V): 20 A
Max output current (+12V): 54 A
Max output current (+5Vsb): 3 A
Max output current (+5V): 20 A
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Height: 86 mm
Depth: 140 mm
Width: 150 mm
Performance
ATX version: 3.1
Purpose: PC
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Gold
Mean time between failures (MTBF): 100000 h
Packaging data
Package type: Box
Packaging content
Cables included: AC, CPU, PCIe, Peripheral (Molex) to SATA 3.3, SATA
Ports & interfaces
Peripheral (Molex) power connectors (4-pin): 1
Cabling type: Fully-Modular
Number of PATA power connectors: 2
