Technical details
Sustainability certificates: ENERGY STAR
Design
Cooling type: Passive
On/off switch: Yes
Product colour: Black
Power
Max output current (+5Vsb): 3 A
Max output current (-12V): 0.3 A
Combined power (+5Vsb): 15 W
Input current: 4.5 - 9.5 A
AC input voltage: 100 - 240 V
Max output current (+5V): 20 A
AC input frequency: 50 - 60 Hz
Power protection features: Short circuit, Over voltage, Under voltage, Over current, Over power
Combined power (-12V): 3.6 W
Combined power (+12V): 696 W
Max output current (+3.3V): 20 A
Combined power (+5V): 100 W
Efficiency: 94%
Combined power (+3.3V): 100 W
Max output current (+12V): 58 A
Total power: 700 W
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Weight & dimensions
Width: 150 mm
Depth: 170 mm
Height: 86 mm
Performance
Purpose: PC
Supported motherboard form factors: ATX
Mean time between failures (MTBF): 150000 h
80 PLUS certification: 80 PLUS Titanium
Power supply unit (PSU) form factor: ATX
Packaging data
Package type: Box
Certification: cTUVus, TUV, CB, CCC, BSMI, EAC, CE, WEEE, ErP Lot 6, REACH
Certificates
Compliance certificates: RoHS
Ports & interfaces
Motherboard power connector: 20+4 pin ATX
CPU power cable length: 65 cm
Peripheral (Molex) power cable length: 300, 470, 690 mm
CPU power connectors (8-pin): 2
Number of SATA power connectors: 3
PCI Express power cable length: 75 cm
SATA power cable length: 810 mm, 800, 450
PCI Express power connectors (6+2 pin): 4
Peripheral (Molex) power connectors (4-pin): 3
Motherboard power cable length: 61 cm
Cabling type: Fully-Modular
Logistics data
Harmonized System (HS) code: 84733020
