Design Fan diameter: 12 cm On/off switch: Yes Product colour: Black
Power Max output current (+5Vsb): 3 A Max output current (-12V): 0.5 A Max output current (+5V): 25 A Combined power (+3.3V): 125 W Combined power (-12V): 6 W AC input frequency: 50/60 Hz Max output current (+3.3V): 25 A Combined power (+12V): 1600 W Max output current (+12V): 133.3 A Total power: 1600 W AC input voltage: 100 - 240 V Input current: 15 A Combined power (+5Vsb): 15 W
Operational conditions Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Width: 210 mm Height: 86 mm Depth: 150 mm
Performance Noise level: 10 dB Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 3.1 Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Titanium Certification: REACH, RoHS, Energy Star, ErP Lot 6, WEEE
Ports & interfaces PCI Express power cable length: 75 cm ATX power connector (12+4 pin): Yes Peripheral (Molex) power cable length: 690 mm CPU power cable length: 70 cm Number of SATA power connectors: 4 PCI Express power connectors (8-pin): 1 SATA power cable length: 950 mm CPU power connector (4+4 pin): Yes Motherboard power connector: 24-pin ATX Cabling type: Fully-Modular Peripheral (Molex) power connectors (4-pin): 3 Motherboard power cable length: 61 cm
