Design
Cooling type: Active
Fan diameter: 13.5 cm
On/off switch: Yes
Product colour: Black
Number of fans: 1 fan(s)
Power
Power protection features: Under voltage, Over current, Short circuit, Over voltage, Over power
AC input voltage: 100 - 240 V
Input current: 15 - 7.5 A
Combined power (+5V): 125 W
Max output current (+3.3V): 25 A
Combined power (-12V): 3.6 W
Combined power (+3.3V): 125 W
Max output current (+5Vsb): 3 A
Max output current (+12V): 100 A
Max output current (-12V): 0.3 A
Combined power (+12V): 1200 W
Max output current (+5V): 25 A
Total power: 1200 W
Combined power (+5Vsb): 15 W
AC input frequency: 50 - 60 Hz
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Weight & dimensions
Width: 150 mm
Height: 86 mm
Depth: 160 mm
Performance
Mean time between failures (MTBF): 150000 h
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
Purpose: PC
ATX version: 3.0
Bearing technology: FDB
Packaging data
Package type: Box
Packaging content
Cables included: AC, CPU, PCIe, Peripheral (Molex), Peripheral (Molex) to SATA 3.3, SATA
Cable tie(s) included: Yes
Ports & interfaces
Number of SATA power connectors: 4
Peripheral (Molex) power connectors (4-pin): 1
SATA power cable length: 950 mm
Cabling type: Fully-Modular
Motherboard power connector: 20+4 pin ATX
Motherboard power cable length: 61 cm
Peripheral (Molex) power cable length: 690 mm
CPU P4 connector (4-pin): 2
ATX power connector (20+4 pin): Yes
CPU power cable length: 65 cm
Logistics data
Warranty period: 10 year(s)
Safety warning
Warnings: Do not open the case - risk of electric shock., Avoid contact of the product with water or other liquids., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
