Design Product colour: Black Cooling type: Active Fan diameter: 12 cm Number of fans: 1 fan(s) Fan location: Top On/off switch: Yes
Power AC input frequency: 50/60 Hz Power protection features: Under voltage, Over current, Over power, Short circuit, Over voltage, Overheating Combined power (+3.3V): 100 W AC input voltage: 100 - 240 V Max output current (+12V1): 83.3 A Max output current (+5V): 20 A Input current: 12 / 6 A Max output current (+5Vsb): 3 A Max output current (-12V): 0.3 A Total power: 1000 W Combined power (+12V): 1000 W Combined power (+5V): 100 W Max output current (+3.3V): 20 A
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Height: 86 mm Depth: 140 mm Weight: 1.7 kg Width: 150 mm
Performance Power supply unit (PSU) form factor: ATX ATX version: 3.1 Mean time between failures (MTBF): 100000 h 80 PLUS certification: No Purpose: PC Bearing technology: FDB
Packaging content Cables included: AC
Certificates Compliance certificates: CE, Federal Communications Commission (FCC), CB
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 1 Motherboard power connector: 24-pin ATX ATX Power connector (24-pin): Yes Motherboard power cable length: 60 cm CPU power connector (4+4 pin): Yes PCI Express connector: Yes Cabling type: Fully-Modular CPU power cable length: 70 cm EPS power connector (4+4 pin): Yes PCI Express power cable length: 70 cm Number of SATA power connectors: 11 PCI Express power connectors (6+2 pin): 4
