Design On/off switch: Yes Fan location: Top Fan diameter: 12 cm Number of fans: 1 fan(s) Cooling type: Active Product colour: White
Power Max output current (+5V): 20 A Combined power (+3.3V): 100 W Total power: 1000 W Combined power (+12V): 1000 W Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over current, Over power Max output current (+12V1): 83.3 A Max output current (+5Vsb): 3 A Combined power (+5V): 100 W Max output current (+3.3V): 20 A Max output current (-12V): 0.3 A Input current: 12 / 6 A AC input frequency: 50/60 Hz AC input voltage: 100 - 240 V
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Weight: 1.7 kg Height: 86 mm Depth: 140 mm Width: 150 mm
Performance Bearing technology: FDB Purpose: PC Mean time between failures (MTBF): 100000 h 80 PLUS certification: No ATX version: 3.1 Power supply unit (PSU) form factor: ATX
Packaging content Cables included: AC
Certificates Compliance certificates: CE, Federal Communications Commission (FCC), CB
Ports & interfaces Motherboard power cable length: 60 cm Cabling type: Fully-Modular EPS power connector (4+4 pin): Yes CPU power cable length: 70 cm CPU power connector (4+4 pin): Yes Number of SATA power connectors: 11 PCI Express power connectors (6+2 pin): 4 Peripheral (Molex) power connectors (4-pin): 1 Motherboard power connector: 24-pin ATX ATX Power connector (24-pin): Yes PCI Express power cable length: 70 cm PCI Express connector: Yes
