Design Fan location: Top Product colour: Black On/off switch: Yes Fan diameter: 12 cm Cooling type: Active Number of fans: 1 fan(s)
Power Max output current (+5Vsb): 3 A Max output current (+5V): 20 A Combined power (+12V): 1200 W Total power: 1200 W Input current: 14 / 7 A AC input voltage: 100 - 240 V Power protection features: Short circuit, Over voltage, Over power, Overheating, Under voltage, Over current Combined power (+5V): 100 W Max output current (+3.3V): 20 A Max output current (+12V1): 100 A AC input frequency: 50/60 Hz Combined power (+3.3V): 100 W Max output current (-12V): 0.3 A
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Weight: 1.7 kg Height: 86 mm Width: 150 mm Depth: 140 mm
Performance 80 PLUS certification: No Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h Purpose: PC Bearing technology: FDB ATX version: 3.1
Packaging content Cables included: AC
Certificates Compliance certificates: Federal Communications Commission (FCC), CB, CE
Ports & interfaces PCI Express connector: Yes Number of SATA power connectors: 11 PCI Express power cable length: 70 cm EPS power connector (4+4 pin): Yes CPU power connector (4+4 pin): Yes Motherboard power connector: 24-pin ATX Cabling type: Fully-Modular Peripheral (Molex) power connectors (4-pin): 1 CPU power cable length: 70 cm PCI Express power connectors (6+2 pin): 4 Motherboard power cable length: 60 cm ATX Power connector (24-pin): Yes
