Design Fan location: Top Fan diameter: 9.2 cm Number of fans: 1 fan(s) On/off switch: Yes Cooling type: Active Product colour: Black
Power Combined power (+12V): 750 W AC input frequency: 50/60 Hz Max output current (-12V): 0.3 A Max output current (+12V1): 62.5 A Max output current (+5V): 20 A Power protection features: Over power, Short circuit, Over voltage, Under voltage, Over current, Overheating Input current: 10 / 6 A Combined power (+5V): 100 W Max output current (+3.3V): 20 A AC input voltage: 100 - 240 V Max output current (+5Vsb): 3 A Combined power (+3.3V): 100 W Total power: 750 W
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Depth: 100 mm Height: 63.5 mm Width: 125 mm Weight: 1 kg
Performance 80 PLUS certification: No Mean time between failures (MTBF): 100000 h Bearing technology: FDB Purpose: PC Power supply unit (PSU) form factor: SFX
Packaging content Cables included: AC
Certificates Compliance certificates: CB, Federal Communications Commission (FCC), CE
Ports & interfaces EPS power connector (8-pin): Yes EPS power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 2 Number of SATA power connectors: 8 Motherboard power connector: 24-pin ATX PCI Express connector: Yes Peripheral (Molex) power connectors (4-pin): 1 Motherboard power cable length: 30 cm ATX Power connector (24-pin): Yes CPU power cable length: 42 cm CPU power connector (4+4 pin): Yes Cabling type: Fully-Modular PCI Express power cable length: 57 cm
