Design Fan location: Top Cooling type: Active Number of fans: 1 fan(s) Fan diameter: 9.2 cm On/off switch: Yes Product colour: Black
Power Max output current (-12V): 0.3 A Total power: 850 W Combined power (+3.3V): 100 W Max output current (+3.3V): 20 A Combined power (+12V): 850 W Combined power (+5V): 100 W AC input voltage: 100 - 240 V Power protection features: Under voltage, Over current, Short circuit, Over voltage, Overheating, Over power Max output current (+12V1): 70.8 A Max output current (+5Vsb): 3 A Max output current (+5V): 20 A AC input frequency: 50/60 Hz Input current: 12 / 6 A
Operational conditions Operating temperature (T-T): 0 - 40 °C
Weight & dimensions Height: 63.5 mm Depth: 100 mm Width: 125 mm Weight: 1 kg
Performance Purpose: PC Mean time between failures (MTBF): 100000 h 80 PLUS certification: No Power supply unit (PSU) form factor: SFX Bearing technology: FDB
Packaging content Cables included: AC
Certificates Compliance certificates: CE, Federal Communications Commission (FCC), CB
Ports & interfaces Cabling type: Fully-Modular CPU power connector (4+4 pin): Yes Motherboard power cable length: 30 cm EPS power connector (4+4 pin): Yes PCI Express power cable length: 57 cm PCI Express connector: Yes PCI Express power connectors (6+2 pin): 2 Number of SATA power connectors: 8 ATX Power connector (24-pin): Yes Peripheral (Molex) power connectors (4-pin): 1 Motherboard power connector: 24-pin ATX EPS power connector (8-pin): Yes CPU power cable length: 42 cm
