Design Cooling type: Active Fan diameter: 13.5 cm On/off switch: Yes Number of fans: 1 fan(s) Product colour: White Fan location: Top
Power AC input voltage: 100 - 240 V AC input frequency: 50/60 Hz Power protection features: Short circuit, Over voltage, Under voltage, Over current, Overheating Total power: 1000 W Combined power (+3.3V): 120 W Max output current (+3.3V): 24 A Combined power (+5V): 120 W Combined power (+12V): 1000 W Maximum input current (@220V): 6 A Max output current (+5V): 24 A Max output current (+12V): 83.3 A Max output current (+5Vsb): 3 A Maximum input current (@110V): 12 A Max output current (-12V): 0.5 A
Operational conditions Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Depth: 160 mm Height: 86 mm Width: 150 mm Weight: 1.7 kg
Performance Mean time between failures (MTBF): 100000 h Purpose: PC 80 PLUS certification: 80 PLUS Gold ATX version: 3.0 Power supply unit (PSU) form factor: ATX
Packaging content Cables included: AC
Certificates Compliance certificates: CB, CE, UKCA, Federal Communications Commission (FCC)
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 Floppy disk drive connector: Yes PCI Express power connectors (6+2 pin): 4 Cabling type: Fully-Modular Motherboard power cable length: 62 cm Peripheral (Molex) power cable length: 550 Number of SATA power connectors: 12 Motherboard power connector: 20+4 pin ATX ATX power connector (20+4 pin): Yes Floppy drive power connector: 1 CPU power connector (4+4 pin): Yes
