Design On/off switch: Yes Fan location: Top Product colour: Black Cooling type: Active Number of fans: 1 fan(s) Fan diameter: 13.5 cm
Power AC input frequency: 50/60 Hz Max output current (+3.3V): 24 A Max output current (+5Vsb): 3 A Maximum input current (@110V): 15 A Combined power (+5V): 120 W Max output current (-12V): 0.5 A AC input voltage: 100 - 240 V Max output current (+5V): 24 A Power protection features: Under voltage, Over current, Short circuit, Over voltage, Overheating Max output current (+12V): 108.3 A Combined power (+3.3V): 120 W Maximum input current (@220V): 8 A Combined power (+12V): 1300 W Total power: 1300 W
Operational conditions Operating temperature (T-T): 0 - 50 °C
Weight & dimensions Weight: 1.75 kg Depth: 160 mm Height: 86 mm Width: 150 mm
Performance ATX version: 3.0 Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold Purpose: PC Power supply unit (PSU) form factor: ATX
Packaging content Cables included: AC
Certificates Compliance certificates: UKCA, Federal Communications Commission (FCC), CE, CB
Ports & interfaces EPS power connector (8-pin): Yes Number of SATA power connectors: 12 Peripheral (Molex) power connectors (4-pin): 2 Motherboard power cable length: 62 cm Motherboard power connector: 20+4 pin ATX ATX power connector (20+4 pin): Yes CPU power connector (4+4 pin): Yes Floppy disk drive connector: Yes Floppy drive power connector: 1 Cabling type: Fully-Modular PCI Express power connectors (6+2 pin): 8
